Specifications

CPU Compatibility

• Socket: LGA1700
• Supported Processors:
  • Intel® Core™ 14th, 13th, and 12th Gen
  • Intel® Pentium® Gold and Celeron®
• Technology Support:
  • Intel® Turbo Boost 2.0
  • Intel® Turbo Boost Max 3.0 (depends on CPU)

Chipset

• Intel® B660 Chipset

Memory

• Slots: 4 x DDR5 DIMM
• Max Capacity: 196GB
• Supported Speeds (Overclocked): 6000 / 5800 / 5600 / 5400 / 5200 / 5000 / 4800 MHz
• Memory Architecture: Dual Channel
• Features:
  • Intel® XMP support
  • ASUS OptiMem II

Graphics Support

(Integrated graphics require a compatible Intel CPU)

• Ports:
  • 1 x DisplayPort (Supports 8K @ 60Hz, DP 1.4)
  • 1 x HDMI 2.1 (Supports 4K @ 60Hz)

Expansion Slots

• PCIe 5.0 x16 (for GPUs, full x16 mode)
• PCIe 3.0 x16 (x4 mode, shares bandwidth with PCIe x1 slots)
• PCIe 3.0 x1 (2 slots)
• Intel® Optane™ Memory support

Storage

• M.2 Slots:
  • M.2_1: PCIe 4.0 x4 (2242/2260/2280/22110)
  • M.2_2: PCIe 4.0 x4 (2242/2260/2280/22110)
  • M.2_3: PCIe 3.0 x4 (2242/2260/2280)
• SATA Ports: 4 x SATA 6Gb/s
• RAID Support: RAID 0/1/5/10

Networking

• Ethernet: Intel® 2.5Gb LAN (with ASUS LANGuard)
• Wi-Fi: Wi-Fi 6 (2x2, supports 2.4/5GHz bands)
• Bluetooth: v5.2

USB Ports

Rear I/O (9 Total)

• 1 x USB 3.2 Gen 2x2 (Type-C)
• 1 x USB 3.2 Gen 2 (Type-A)
• 5 x USB 3.2 Gen 1 (4 x Type-A, 1 x Type-C)
• 2 x USB 2.0 (Type-A)

Front Panel (7 Total)

• 1 x USB 3.2 Gen 2 (Type-C)
• 1 x USB 3.2 Gen 1 Header (Supports 2 additional ports)
• 2 x USB 2.0 Headers (Supports 4 additional ports)

Audio

• Chipset: ROG SupremeFX 7.1 ALC4080
• Features:
  • High-quality 120 dB SNR playback, 113 dB SNR recording
  • 32-bit/384kHz support
  • Impedance sensing
  • Savitech SV3H712 AMP
  • Premium audio capacitors
  • SupremeFX shielding

Rear I/O Panel

• USB Ports: 9 (see USB section)
• Display Outputs: 1 x DisplayPort, 1 x HDMI
• Networking: 1 x Intel 2.5Gb Ethernet, Wi-Fi module
• Audio: 5 x 3.5mm jacks
• Others:
  • 1 x BIOS FlashBack™ Button
  • 1 x Clear CMOS Button

Internal Headers & Connectors

Cooling & Power

• Fan Headers:
  • 1 x CPU Fan
  • 1 x CPU OPT Fan
  • 1 x AIO Pump
  • 4 x Chassis Fan
• Power Connectors:
  • 1 x 24-pin ATX
  • 1 x 8-pin +12V
  • 1 x 4-pin +12V

Storage & USB

• M.2 Slots: 3 x M.2 (see Storage section)
• SATA Ports: 4 x SATA 6Gb/s
• USB Headers:
  • 1 x USB 3.2 Gen 2 (Type-C)
  • 1 x USB 3.2 Gen 1 (2 additional ports)
  • 2 x USB 2.0 (4 additional ports)

RGB & Miscellaneous

• RGB Headers:
  • 3 x Addressable Gen 2
  • 1 x AURA RGB
• Other Headers:
  • 1 x Front Panel Audio (AAFP)
  • 1 x S/PDIF Out
  • 1 x SPI TPM
  • 1 x System Panel
  • 1 x Thermal Sensor
  • 1 x Thunderbolt™

Special Features

ASUS Q-Design

• M.2 Q-Latch
• Q-DIMM
• Q-LED (CPU, DRAM, VGA, Boot indicators)
• Q-Slot

ASUS EZ DIY

• BIOS FlashBack™ Button & LED
• Pre-mounted I/O Shield
• SafeSlot & SafeDIMM

Thermal Solutions

• M.2 Heatsinks & Backplate

Software Features

ROG Exclusive Software

• GameFirst VI
• Sonic Studio III (with Virtual Mixer & Suite Companion)
• Sonic Radar III
• DTS® Sound Unbound
• ROG CPU-Z
• Anti-Virus Software

ASUS Exclusive Software

• Armoury Crate
• AURA Sync & AURA Creator
• Fan Xpert 4
• AI Suite 3 (Performance & Power Management)
• TurboV EVO, EPU, DIGI+ VRM
• MyASUS & WinRAR

BIOS & Manageability

• UEFI BIOS (EZ Mode, EZ Flash 3, CrashFree BIOS 3)
• MemTest86 Support
• WOL by PME, PXE

Accessories Included

• Cables: 4 x SATA 6Gb/s
• Wi-Fi Antennas: 1 x ASUS Wi-Fi Moving Antennas
• Miscellaneous:
  • 1 x Cable Ties Pack
  • 1 x M.2 Rubber Package
  • 1 x M.2 Q-Latch Package
  • 1 x M.2 Q-Latch Package (for backplate)
  • 1 x ROG Key Chain
  • 1 x ROG Stickers
  • 1 x ROG Thank You Card
• Installation Media: Support DVD
• Documentation: User Manual

Operating System Support

• Windows® 10 (64-bit)
• Windows® 11 (64-bit)

Form Factor

• ATX (30.5 cm x 24.4 cm)
