SAPPHIRE RX 9060XT 16GB 128BIT GDDR6 PURE GAMING OC WHITE (2XHDMI, DP)

Product Description:

Digital Power Design in the SAPPHIRE PURE AMD Radeon™ RX 9000 Series ensures precise power delivery for peak performance and stability. Engineered for exceptional efficiency, it minimizes power loss even under intense workloads. This advanced power architecture guarantees smoother operation and longer-lasting hardware reliability.

Product Specifications:

• GPU: AMD Radeon™ RX 9060 XT
• Architecture: AMD RDNA™ 4
• Compute Units: 32 CUs (3rd Gen Ray Tracing + 2nd Gen AI Accelerators)
• Stream Processors: 2048
• Ray Accelerators: 32
• AI Accelerators: 64
• Infinity Cache: 32MB
• Boost Clock: Up to 3290 MHz
• Game Clock: Up to 2700 MHz
• Boost Clock Note: Maximum frequency achievable under burst workloads
• Game Clock Note: Expected GPU clock during typical gaming workloads
• Memory Size: 16GB GDDR6
• Memory Bus: 128-bit
• Memory Clock: 20 Gbps Effective
• Maximum Displays: 3
• Maximum Resolution (HDMI®): 7680×4320
• Maximum Resolution (DisplayPort™ 2.1a): 7680×4320
• Video Output Ports:
  • 2 x HDMI®
  • 1 x DisplayPort™ 2.1a
• Interface: PCI Express® 5.0 x16
• Cooler Type: Dual-X Cooling
• Cooling Features:
  • AeroCurve Fan Blade
  • Free Flow Cooling
  • Integrated Cooling Module
  • Optimized Composite Heatpipes
  • High TG Copper PCB (10-layer, 2oz Copper)
  • Two-Ball Bearing Fans
  • Intelligent Fan Control
  • Precision Fan Control
• Thermal Interface Material: Honeywell PTM7950 TIM
• Lighting & RGB:
  • ARGB SAPPHIRE Logo
  • External RGB LED Motherboard Synchronization (3-pin header)
  • Glow! RGB control via TriXX Software
• Durability Features:
  • FrameDefense Reinforced Frame Design
  • Tough Metal Backplate
  • Fuse Protection on PCI-E Power Connector
• Power Design: 9-Phase Digital Power Design
• Power Connector: 1 x 8-pin
• Typical Board Power: 170W
• Minimum PSU Requirement: 450W
• BIOS: UEFI
• Software Support:
  • AMD Software: Adrenalin Edition™
  • SAPPHIRE TriXX Utility
  • TriXX Features:
    • Performance vs. Efficiency Quicksets
    • TriXX Boost
    • Glow! Lighting Control
• AMD Technologies:
  • AMD HYPR-RX with AFMF 2
  • AMD FidelityFX™ Super Resolution 4 with AI Upscaling
  • AMD Radiance Display™ Engine
  • AMD Fluid Motion Frames 2
  • AMD Radeon™ Anti-Lag 2
  • AMD Noise Suppression
  • AMD Freesync™ Technology
  • AV1 Encode/Decode
  • Microsoft® DirectX® 12 Ultimate
  • AMD Smart Technologies
  • AMD FidelityFX™ Technologies
• Form Factor: ATX
• Slot Size: 2.3-slot
• Dimensions: 240mm (L) x 124mm (W) x 46.1mm (H)
• Operating System Support:
  • Linux®
  • Windows® 10 (64-bit)
  • Windows® 11 (64-bit)
• System Requirements:
  • PCI Express® x16 slot
  • 1 x 8-pin PCI-E Power Connector
  • Minimum 8GB RAM (16GB recommended)
  • Minimum 450W Power Supply
• Accessories Included: 3-pin 5V ARGB Cable
